RiverRidge 06-037 - STEP 2

STEP 1
L
STEP 1
1. Attach drawer left side panel (9) to drawer back board (11) by inserting 2 long wood screws (L) through holes
on drawer left side panel (9) and tighten into drawer back board (11).
2. Attach drawer right side panel (10) to drawer back board (11) by inserting 2 long wood screws (L) through holes
on drawer right side panel (10) and tighten into drawer back board (11).
3. Slide drawer bottom board (12) into grooves on drawer left side panel (9) and right side panel (10) and drawer
back board (11).
STEP 2
STEP 2
1. Screw 2 cam bolts (B) into pre-threaded holes on drawer front board (8).
2. Insert 4 wood dowels (A) into dowel holes on the drawer front board (8).
L
11
10
9
12
