5. COMMUNICATION IDENTIFIERS
IMSRM04-E8
40
Continued from the previous page
Name
Iden-
tifier
Digits
Attri-
bute
Data range
Factory
set
value
Refer-
ence
page
Temperature rise
completion range
HD
6 R/W 1 to 10 °C or 1 to 20 °F10°C
20°F
46
Temperature rise
completion trigger
HS
1 R/W 0: Unused 1: Used 0
Temperature rise
completion soak time
T3
6 R/W 0 to 360 min. 0
LBA alarm condition
AP
1 RO 0: OFF 1: ON
−
66
LBA use selection
HP
1 R/W 0: Unused 1: Used 0 66
LBA time
C6
6 R/W 1 to 7200 sec. 480
LBA deadband
V2
6 R/W Input span 0
Local/Computer transfer
C1
1 RO 0: Local mode
1: Computer mode
(Only valid when connected
with the Operation Pane)
−
70
*1 Heat control: 0
Heat/cool control: 2
*2 Depends on specifications
*3 Relay contact output: 20
Voltage pulse output, open collector output, triac output: 2
To Next Page
