34 • Viewing and Changing Global Parameters Beacon 410 Gas Monitor Operator’s Manual
3. In the parameter screens, use the ENTER button to accept a displayed parameter
setting and proceed to the next parameter or the ESCAPE button to backup a screen.
4. If you want to change a displayed parameter setting, use the UP/YES or DOWN/NO
button to change the parameter to the desired setting, then press and release the
ENTER button to accept the change and proceed to the next screen.
5. Continue through the parameter setting screens changing any parameter settings as
needed until the following message appears on the display.
6. To save the channel parameter settings, press and release the UP /YES button.The
screen will indicate that the Beacon 410 is saving the settings for a few seconds then
the Beacon 410 will return to normal operation.
If you do not want to save the channel parameter settings, press and release the
DOWN/NO button. The display will indicate that no settings have been changed for a
few seconds then the Beacon 410 will return to normal operation.
Table 6 below lists the channel parameters that can be configured in the Configuration
Menu along with the factory set value for each parameter.
Table 6: Global Menu Parameters
Global Parameter
(Factory-Set Value)
Description
STROBE Installation
(Factory setting depends on
whether a strobe is supplied
with the Beacon 410.)
If set to STROBE IS INSTALLED, the strobe circuitry is functional
and items in the Configuration Menu that apply to the strobe
operation become active.
If set to NO STROBE INSTALLED, the strobe circuitry does not
function and items in the Configuration Menu that apply to the
strobe operation do not appear.
NORMAL RELAY STATES
(NORM DE-ENERGIZED)
If set to NORM DE-ENERGIZED, the gas alarm relays are de-
energized in normal operation and energize when the appropriate
alarm circuit is activated. The NO (normally open) relay contacts
are open during non-alarm operation and close when the
appropriate alarm condition occurs. The NC (normally closed)
relay contacts are closed during non-alarm operation and open
when the appropriate alarm condition occurs.
If set to NORMALLY ENERGIZED, the gas alarm relays are
energized in normal operation and de-energize when the
appropriate alarm circuit is activated. The NO (normally open)
relay contacts are closed during non-alarm operation and open
when the appropriate alarm condition occurs. The NC (normally
closed) relay contacts are open during non-alarm operation and
close when the appropriate alarm condition occurs.
NOTE: The fail relay is factory set as normally energized and is
not field adjustable.
]
ACS
Ssgnitt?
[kto bac up]EP
NY[
e
E
a
ve S
/
