Robe 575 AT - DMX Protocol Details; Colour Wheel and Macros

14
15
Mode/Channel
Value Function
Type of
control
1 2 3 4
7 7 9 9
0
21
43
64
85
107
128-129
130-141
142-153
154-165
166-177
178-189
190 - 215
216 - 217
218 - 243
244 - 249
250 - 255
Colour wheel
Continual positioning
Open/white
Deep red
Deep blue
Green
6000K correction lter
UV lter
White
Positioning
Deep red
Deep blue
Green
6000K correction lter
UV lter
Forwards rainbow effect from fast to slow
No rotation
Backwards rainbow effect from slow to fast
Random colour selection by audio control
(Set microphone sensitivity in menu „Personality”)
Auto random colour selection from fast to slow
proportional
proportional
proportional
proportional
proportional
proportional
proportional
step
step
step
step
step
proportional
step
proportional
step
proportional
8 10
0 - 255
Colour wheel - ne positioning
Fine positioning proportional
9 8 11 10
0 - 255
Cyan
Cyan (0-white, 255-full cyan) proportional
10 9 12 11
0 - 255
Magenta
Magenta (0-white, 255-full magenta) proportional
11 10 13 12
0 - 255
Yellow
Yellow (0-white, 255-full yellow) proportional
12 11 14 13
0 - 255
Conversion temperature lter 3200K
(0-7200K, 255-3200K) proportional
13 12 15 14
0 - 255
Speed of CMY and conv.temp. lter
Speed from max. (0) to min.(255)
proportional
14 13 16 15
0 - 7
8 - 15
16 -23
24-31
32-39
40-47
48-55
56-63
64-71
72-79
80-87
88-95
96-103
104-111
112-119
120-127
128-135
136-143
144-151
152-159
160-167
168-175
176-183
CMY colour macros
No function
Macro 1
Macro 2
Macro 3
Macro 4
Macro 5
Macro 6
Macro 7
Macro 8
Macro 9
Macro 10
Macro 11
Macro 12
Macro 13
Macro 14
Macro 15
Macro 16
Macro 17
Macro 18
Macro 19
Macro 20
Macro 21
Macro 22
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
