29
head is not located in the default position after the reset.
MA.Er.(Master error)
The message informs you that the xture was addressed as a master and DMX signal is connected to its
input.Disconnect the DMX controller from xture's input and address the xture as the master again.
t.M.Er.(Temperature measuring error)
The message informs you that the communication betwen the head and the main board in the xture base was
cut off (or the head temperature sensor is defective) and the lamp was automatically switched off.
12. Technical specications
Power supply:
EU-model: Voltage:...........................208/230/240V AC, 50/60Hz ~
Fuse:...............................T 6.3A@230V
US-model: Voltage:...........................100/120/208/230/240V AC, 50/60Hz ~
Fuse:................................T 10A@120V
Power consumption:.........720 VA
Lamp:
Philips MSR 575/2, 95V/575W GX-9,5
Optical System:
- High luminous-efciency glass reector
- linear zoom 12°-34°
Colour wheel:
-5 replaceable 'SLOT&LOCK' dichroic lters (including 6000 K and UV lter) + open
Strobe:
- Strobe effect with variable speed (max.15 ashes per second)
Dimmer:
- Smooth dimmer from 0 - 100 %
Effects:
- Frost lter
- Rotatable beam shaper ,indexable 360° with continuous rotation
Zoom
- Motorized zoom, range depends on the front lens and the zoom lens:
Standard front Fresnel lens+standard zoom lens Beam angle Intensity-center (Lux)at 5 m
Without zoom lens 8° 27744
Minimum zoom 12° 22400
Maximum zoom 34° 10496
Standard front Fresnel lens+wide-angle lens D114 Beam angle Intensity-center (Lux)at 5 m
Minimum zoom 24° 8192
Maximum zoom 60° 2445
Front wide-angle lens (optional)without zoom lens Beam angle Intensity-center (Lux)at 5 m
87° 666
CMY-colours mixing module
- Smooth CMY colour mixing system
- Colour temperature correction lter lowers the colour temperature from 7200K to 3200 K
- 30 colour macros
Motors:
- 13 high quality stepping-motors controlled by microprocessors
Electronics:
