ColorWash 575 AT has been powered on since the counter was last reset.In order to
reset this counter to 0 you have to hold [UP] and[DOWN ] and press the [ENTER].
LA.St. --- Lamp strikes.Select this submenu to read the total number of the lamp strikes.
totL --- The function shows the total number of the lamp strikes since the ColorWash
575 AT has been fabricated.
rSEt --- The function shows the number of the lamp strikes since the counter was last
reset.In order to reset this counter to 0 you have to hold [UP] and[DOWN ] and press
[ENTER].
tEMP ---Fixture temperatures.Select this submenu to read the xture temperatures (°C).Please note that the
outside temperature should not exceed 40° C.
Cur.t. --- Current xture temperatures.
boAr.-Current temperature on the main board in the base of the
xture.Temperatures above 66°C lead to the lamp being switched off
and the fixture goes to "low power mode".Before switching the lamp on
again (after 5 minutes),run a total xture reset.
HEAd-Current temperature of the head inside.Temperatures below 66°C
are not critical. 66° C and more lead to the lamp being switched off and the
xture goes to "low power mode".Before switching the lamp on again (after
5 minutes),run a total xture reset.
Hi.tE. --- Maximum xture temperatures.
boAr.- The function shows the max.temperature on the main board since
the ColorWash 575 AT has been fabricated.
HEAd - The function shows the max.temperature of the head inside since
the ColorWash 575 AT has been fabricated.
rSEt --- Maximum resetable temperatures.
boAr. - The function shows the maximum temperature on the main board
since the counter was last reset.In order to reset the counter to 0 you have
to hold [UP] and[DOWN ] and press the [ENTER].
HEAd - The function shows the maximum temperature of the head inside
since the counter was last reset.In order to reset the counter to 0 you have
to hold [UP] and[DOWN ] and press the [ENTER].
DM.In.--- Readout of DMX values.Select this function to read DMX values (0-255) of each channel received
by the xture.
PAn a coarse pan movement C.SPd. a CMY/CTC/dimmer speed
F.PAn a ne pan movement Macr. a CMY macros
tilt a coarse tilt movement EFFE. an effect wheel
F.tilt a ne tilt movement EF.ro. a beam shaper rotation
SpEd a pan/tilt speed F.E.ro. a fine beam rotation
P.t.SE. a pan/tilt macro selection Zoom a zoom
P.t.SP. a pan/tilt speed F.Zom. a ne zoom
Func. a special function Stro. a strobe,shutter
Colo. a colour wheel dimr a shutter,strobe
F.Col. a ne colour wheel F.dim. a ne dimmer
CYAN a cyan lamella
MAGE. a magenta lemella
YELL. an yellow lamela
CtC.F. a CTC lter
VErS. --- Software version.Select this function to read the software version of processors:
IC1.b.--- Main processor on the main board in the xture base
IC2.b.--- Pan processor on the main board in the xture base
IC3.b. --- Tilt procesor on the main board in the xture base
IC4.b.--- EEprom on the main board in the xture base
IC1.L.--- Processor 1 in the left arm of the xture
IC2.L.--- Processor 2 in the left arm of the xture
IC1.r.--- Processor 1 in the right arm of the xture
