30
There is a calibration protocol:
E󰀨ect Mode 1 Mode 2
Pan channel 40 channel 35
Tilt channel 41 channel 36
Cyan channel 42 channel 37
Magenta channel 43 channel 38
Yellow channel 44 channel 39
Colour Wheel channel 45 channel 40
E󰀨ect Wheel channel 46 channel 41
Static Gobo channel 47 channel 42
Rot. Gobo Wheel channel 48 channel 43
R. Gobo Index 1 channel 49 channel 44
R. Gobo Index 2 channel 50 channel 45
R. Gobo Index 3 channel 51 channel 46
R. Gobo Index 4 channel 52 channel 47
R. Gobo Index 5 channel 53 channel 48
R. Gobo Index 6 channel 54 channel 79
R. Gobo Index 7 channel 55 channel 50
R. Gobo Index 8 channel 56 channel 51
R. Gobo Index 9 channel 57 channel 52
Prism W 1 channel 58 channel 53
Pri W. 1 R.1 channel 59 channel 54
Pri W. 1 R.2 channel 60 channel 55
Pri W. 1 R.3 channel 61 channel 56
Prism W 1 channel 62 channel 57
Pri W. 2 R.1 channel 63 channel 58
Pri W. 2 R.2 channel 64 channel 59
Pri W. 2 R.3 channel 65 channel 60
Frost 1/1 channel 66 channel 61
Frost 1/2 channel 67 channel 62
Frost 2/1 channel 68 channel 63
Frost 2/2 channel 69 channel 64
Zoom channel 70 channel 65
Focus 1 channel 71 channel 66
Focus 2 channel 72 channel 67
Strobe 1/1 channel 73 channel 68
Strobe 1/2 channel 74 channel 69
Strobe 2/1 channel 75 channel 70
Strobe 2/2 channel 76 channel 71
Light Green F channel 77 channel 72
Frost Filter channel 78 channel 73
HotSpot 1 channel 79 channel 74
HotSpot 2 channel 80 channel 75
After having calibrated all e󰀨ects, touch the [conrm] to save adjusted values and reset the xture.
Load Default Calibrations - The item loads default (factory) calibration values.
Updating software - The menu item allows you to switch the xture to the updating mode and to update soft-
ware in the xture via either serial or USB port of PC.
The following is required in order to update software in the xture:
- PC running Windows 7/10 or Linux
- DMX Software Uploader
- Flash cable RS232/DMX P/N.13050624 (if you want to use a serial port of your PC)
- Robe Universal Interface (if you want to use a USB port of your PC)
Note 1: Software update should execute a qualied person. If you lack qualication, do not attempt the update
yourself and ask for help your ROBE distributor.
Note 2: DMX address, IP address, programs 1-3 and all items in the menu "Personality" will be set to their
default (factory) values.
To update software in the xture:
1. DMX Software Uploader program is available from the ROBE web site at WWW.robe.cz.
Save the download le (for example, "DSU_RobinMegapointe_17033149.zip") to a folder on your computer.
