6.3 Tab "Personality"
User mode - The Robin MegaPointe allows you to recall up to 3 user settings. After switching the xture on
for the rst time, the User A settings is active. Now all changes made in the “Personality” menu , ”Addressing”
menu and the “Music Trigger“ and “ Preset Playback“ items from the “Stand-alone” menu are saved to the
User A settings. If you now select the User B settings, from this moment the changes made in these menus will
be saved to the User B settings. After switching the xture o󰀨 and on, the User B setting is active. In this way
you may use the 3 xture operating behaviours.
User A Settings - the function recalls the user A settings.
User B Settings - the function recalls the user B settings.
User C Settings - the function recalls the user C settings.
DMX Preset - Use the menu to select desired channel mode.
Mode 1 - 39 control channels
Mode 2 - 34 control channels
View Selected Preset - Use the menu to display channels included in the selected mode.
Pan/Tilt Settings - Use the menu set behaviour of both pan and tilt movements.
Pan Reverse - The item allows to invert pan movement.
Tilt Reverse - The item allows to invert tilt movement.
Pan/Tilt Feedback - The item allows to return the mowing head to the required pan/tilt position after
changing the position by an external force if this option is set on.
Note. Be careful, the Pan/Tilt Feedback should be permanent On, the option O󰀨 is not suitable for standard
operation and the head of the xture can be damaged!
Pan/Tilt mode - Use this menu to set the mode of the pan/tilt movement
Time mode – The pan and tilt will move with di󰀨erent speeds and they will come at
the same time to the end point of their tracks (pan and tilt use their optimal speeds).
Time of the pan/tilt movement (25.5 sec. max.) is set by the channel "Pan/Tilt speed, Pan/Tilt
time".
Speed Mode - Both Pan and tilt will move with the same speed as adjusted at the channel
"Pan/Tilt speed, Pan/Tilt time".
Pan/Tilt EMS - Built-in electronic motion stabilizer ensures precise position of the xture´s head during its
movement and also reducing its swinging when the truss shakes.
Microphone Sensitivity - Enter the menu if you want to adjust the microphone sensitivity from 1 (max.) to 20
(min.).
Blackout Settings - Use the menu if you need to close the light output under certain conditions which are
described below
Blackout DMC - Blackout during movement correction. Set this option On if you wish to close light
output during the time when the head goes to its correct position, which has been changed by an
external force.
Active Blackouts - Use this menu if you wish to close the light output during e󰀨ect changes.
Pan/Tilt Moving - The menu item enables to close light output while the pan/tilt coordinates
are changing.
Prisms Moving - The menu item enables to close light output while the prism wheel 1
(prismwheel 2 goes from position to position.
CRI Setting - Use this menu to set a desired colour rendering index (CRI).
Standard CRI - CRI=80.
High CRI - CRI=90+
Close Proximity Mode - If this function is on, a light beam temperature is reduced and thanks to this fact the
minimum distance of illuminated objects and the xture can be reduced to 8 m. A min. zoom and power of the
xture is reduced if this mode is active.
Warning: this function is a software aid for operator of the xture and requires increased attention at its using.
Operating the xture with active Close Proximity Mode is at its own risk an we disclaim any responsibility in
case of damage of illuminated objects.
The safety distance between the xture and illuminated objects regardless of software state in the xture is 18m.
