6.6 Tab "Service"
Adjust DMX Values - The menu allows you to set all e󰀨ects to desired positions before ne calibration of the
e󰀨ects .
Calibrations - This menu enables ne calibration of xture e󰀨ects and download default calibration values.
Calibrate E󰀨ects - The menu allows the ne adjustment of e󰀨ects. The menu contains list of e󰀨ects
which can be calibrated:
Pan- a ne pan movement
Tilt - a ne tilt movement
Cyan - a cyan wheel
Magenta - a magenta wheel
Yellow - a yellow wheel
Colour Wheel - a colour wheel
E󰀨ect Wheel - an e󰀨ect wheel
Static Gobo - a static gobo wheel
Rot. Gobo Wheel - a carousel of rotating gobos
R. Gobo Index 1 - a ne movement of rotating gobo 1
R. Gobo Index 2 - a ne movement of rotating gobo 2
R. Gobo Index 3 - a ne movement of rotating gobo 3
R. Gobo Index 4 - a ne movement of rotating gobo 4
R. Gobo Index 5 - a ne movement of rotating gobo 5
R. Gobo Index 6 - a ne movement of rotating gobo 6
R. Gobo Index 7 - a ne movement of rotating gobo 7
R. Gobo Index 8 - a ne movement of rotating gobo 8
R. Gobo Index 9 - a ne movement of rotating gobo 9
Prism W 1- a prism carousel 1
Pri W. 1 R.1 - a ne movement of rotating prism 1 on prism carousel 1
Pri W. 1 R.2 - a ne movement of rotating prism 2 on prism carousel 1
Pri W. 1 R.3 - a ne movement of rotating prism 3 on prism carousel 1
Prism W 1 - a prism carousel 2
Pri W. 2 R.1 - a ne movement of rotating prism 1 on prism carousel 2
Pri W. 2 R.2 - a ne movement of rotating prism 2 on prism carousel 2
Pri W. 2 R.3 - a ne movement of rotating prism 3 on prism carousel 2
Frost 1/1 - a light frost position 1
Frost 1/2 - a light frost position 2
Frost 2/1 - a medium frost position 1
Frost 2/2 - a medium frost position 2
Zoom - a zoom module position
Focus 1 - a focus module position for rot gobo
Focus 2 - a focus module position for static gobo
Strobe 1/1 - a strobe lamella 1 position 1
Strobe 1/2 - a strobe lamella 1 position 2
Strobe 2/1 - a strobe lamella 2 position 1
Strobe 2/2 - a strobe lamella 2 position 2
Light Green F - a minus half green lter position
Frost Filter - an auxiliary optic element position
HotSpot 1 - a hotspot position 1
HotSpot 2 - a hotspot position 2
By using these items you can calibrate and adjust e󰀨ects to their right positions.
Calibration via the control board
1. Disconnect DMX controller from the xture and enter the "Calibrate E󰀨ects" menu.
2. Use the [up arrow] and [down arrow] to nd desired e󰀨ect and touch it to enter the ne e󰀨ect adjustment
screen.
3. Set desired value and save it by touching the [conrm].
4. Repeat steps 2 and 3 for the next e󰀨ects.
5. After calibrating all e󰀨ects, touch the [conrm] to save all adjusted values and reset the xture.
Calibration via the DMX controller
1. Connect DMX controller to the xture and set xture e󰀨ects to the desired positions before ne calibration.
2. Enter the "Calibrate E󰀨ects" menu and now you can calibrate desired e󰀨ects by a DMX controller.
