Step
Air cleaner 3
Part to remova Procedures
(1) Remove air cleaner cover and element.
6 d Plastic nut
6 d Wing nut
6 d X 2Omm Bolt .--. lpce.
6 d x lOmm Bolt *.-e lpce.
base and crankcase.
cleaner) from stud bolts.
6 Nut --** 2pcs.
(2) Remove air cleaner bracket
(3) Remove breather hose from cleaner
(4) Remove cleaner base and gasket (Air
Remarks Tool
lOmm Box wrench
lOmm Box wrench
CLEANER COVER
6 Q FLANGE NUT: 2pcs. 6 Q FLANGE BOLT
Fig. 17
- 14 -
