2. Exterior of the unit
LCD Display
AC Input
AC 100-240V 50-60Hz
Cooling fan
Stop/Main menu
DEC(-)
INC(+)
Start/Enter
Temperature
sensor port
Charging lead
connector
Balance lead
socket JST-XH
-3-
