13. Specifications
Operating voltage range:................A C100-240Volt
Circuit Power:..............................max. 60W for charging (LD60)
max. 100W for charging (L D100)
max. 10W for discharging
Charge current range:...................0.1 ~ 6.0A (L D 60)
0.1 ~ 10.0A (L D100)
Discharge current range:...............0.1 ~ 2.0A
Current drain for balancing LiPo:....300mA/cell
Battery type/Cell number:..............NiM H/NiCd: 6-8S
LiPo/LiFe/LiHv/LiIo: 2-4S
Pb: 6V(3P) - 12V (6P)
Weight:........................................302g
Dimensions:.................................115x112x55mm
Voltage of one cell in the battery is too low, please
check the voltage of each cell.
Voltage of one cell in the battery pack is too high,
please check the voltage of each cell.
Wrong connection of the connector detected, please
check the connector and cable.
The internal temperature of the unit goes too high.
Cool down the unit.
The processor cannot control the feeding current,
please repair it.
The battery balance port or the power line to the
connector is incorrect.
1: ---mΩ 2: ---mΩ
3: ---mΩ 4: ---mΩ
Battery Pack IR
0mΩ
-18-
BATTERY VOLTAGE
CELL LOW VOL
BATTERY VOL ERR
CELL CONNECT
TEMP OVER ERR
BATTERY VOLTAGE
CELL HIGH VOL
CONTROL FAILURE
