Robland PS 3200 - Setting the Groove Cutter

– English
Silverline - PS 3200 V0713 11
3.1.2 setting the groove cutter
After conrming your choise of the saw blade, you
will be asked an extra control of the R.P.M.
The machine shows the current R.P.M., you must
conrm this is the right speed for this saw blade.
1 groove cutter can be stored the same way as a saw
blade.
Once the groove cutter selected, the whole saw unit
can only be moved up-and down.
It is impossible to groove at an angle.
This procedure is the same as for changing the saw blade. The differences are:
The table insert has to be taken away in order to mount the groove cutter tool.
The maximum dimensions of this tool is 16 mm wide and a body thickness of 12 mm.
The high lighted symbol indicates which value you
change, in this case the saw blade diameter
Min. and max. value
of the saw blade
Numeric eld
Return
Conrm
Screen saw blade settings
