Robomow RC306 User Manual

18
• If the working area borders against a at path
that lies level with the lawn, it is possible to allow
Robomow to run over the path. The Perimeter Wire
should then be laid 10 cm (4 inches) from the edge
of the path.
• When the working area is divided by a at path
that is level with the lawn, it is possible to allow
Robomow to run over the path. The Perimeter Wire
can be laid under the pavement blocks or in the joint
between them.
Important!
The mower must never run over gravel, mulch, or
similar material, which can cause the mower to slip
and damage the blade.
IMPORTANT INFORMATION
If the working area is near a swimming pool,
watercourse, slope greater than 10%, precipice
higher than 50cm (20 inches) or a public road,
the Perimeter Wire must be supplemented with
a fence or alike. The height must then be at least
15cm (6 inches). This will prevent the mower from
ending up outside the working area under any
circumstances.
If such a barrier exists, you may set the Perimeter
Wire 28cm (11 inches) from the barrier.
If there is no fence or the like, then lay the
Perimeter Wire at minimum distance of 1.2m from
the water.
o Maintain a 45° angle in all left-turn corners when
laying the wire along the perimeter. It is not necessary
to maintain 45° angle on right-turn corners along the
perimeter.
o Continue laying the wire, according to your plan.
Gradually pull the wire out of its dispenser and lay it
loosely as you are moving in an anticlockwise direction.
Min 1.2m ( 4ft )
Min 15cm (6”)
Perimiter Wire
28cm (11”)
90
o
45
o
Right turns
Left turns
20cm
10cm (4”)

Robomow RC306 Specifications

General

Type	Robotic lawn mower
Cutting width	280 mm
Cutting system	-
Recommended lawn area	600 m²
Maximum cutting height	60 mm
Minimum cutting height	15 mm
Grass collecting volume	- L
Battery type	LiFePO4
Power source	Battery
Charging time	1 h
Battery voltage	26 V

Weight and Dimensions

Depth	460 mm
Width	630 mm
Height	210 mm
Weight	11400 g
