Robomow RC306 User Manual

33
EN
ok
STOP
Mowing with Edge / Le
arrow
OK to choose /
approve selecon
Mowing without Edge /
Right arrow
GO to Base (Home)
Stop (during operaon) /
Back while in the menu
Sengs
6.3 Manual Operaon
Manual Operation is used when you want to manually send the mower to mow your lawn, regardless the
Automatic Operation’s schedule.
To initiate Manual Operation, while Robomow is at the Base Station, press one of the buttons (except the STOP
button) to show the display.
If the battery is fully charged and the Automatic Operation is enabled (see Section 7.3), then the start time of the
next operation is displayed, otherwise the current day and time are displayed.
Once the display is shown, choose the operation mode you want as provided in the table below:
Operation Mode Child Lock is Off Child Lock is On
Mowing with Edge – Mowing
the edge of the entire lawn before
starting to mow the inner area of
a selected zone.
It is recommended to use this
mode once or twice a week,
depending on how fast the grass
is growing.
Press the ‘Edge before mowing’
(left arrow) button once
Press the ‘Edge before mowing’
(left arrow) button then press OK
Mowing without Edge – Mowing
only the inner area of a selected
zone without the edge.
It is recommended to use this
modeonlyintherstoperationof
each Mowing Cycle.
Press the ‘Mowing’ (right arrow)
button once
Press the ‘Mowing’ (right
arrow) button then press OK
Note–ifaSub-Zoneisdened, L1 (Main Zone) will be displayed when you choose an operating mode. Use the
arrow buttons to scroll and choose the required zone to be mowed and press OK.

Robomow RC306 Specifications

General

Type	Robotic lawn mower
Cutting width	280 mm
Cutting system	-
Recommended lawn area	600 m²
Maximum cutting height	60 mm
Minimum cutting height	15 mm
Grass collecting volume	- L
Battery type	LiFePO4
Power source	Battery
Charging time	1 h
Battery voltage	26 V

Weight and Dimensions

Depth	460 mm
Width	630 mm
Height	210 mm
Weight	11400 g
