Robomow RC306 User Manual

24
4.6 Placement and connection of the Base Station
o Place the Base Station on the Perimeter Wire as shown
intheguretotheright.
o Align the center of the Base Station on the wire.
o Connect the green connector of the perimeter
wire to the Base Station as shown below, while
keeping the right polarity:
o After the Base Station has been positioned, insert 2
stakesintotheBaseStationholesasshowninthegure
to the right. Only after the Base Station position has
been tested during the One-Time Setup process (see
Section 5.2), you will be able to insert the remaining two
stakes.
4.7 Connecting the Power Box
InordertondaproperlocationforthePowerBox,pleaserefertoSection3.3.
For the Power Box installation instructions please refer to Section 4.1.2.
Laying and Fastening Extension Cable
Safety – Avoid injury!
The Extension Cable from the Power Box to the Base Station should
be securely fastened to the ground! It should never present a tripping
hazard.
The Extension Cable should cross ONLY over soft surfaces. It should
not cross over hard surfaces (e.g. Sidewalk, driveway) where it cannot
be securely fastened.

Robomow RC306 Specifications

General

Type	Robotic lawn mower
Cutting width	280 mm
Cutting system	-
Recommended lawn area	600 m²
Maximum cutting height	60 mm
Minimum cutting height	15 mm
Grass collecting volume	- L
Battery type	LiFePO4
Power source	Battery
Charging time	1 h
Battery voltage	26 V

Weight and Dimensions

Depth	460 mm
Width	630 mm
Height	210 mm
Weight	11400 g
