11.6 Splicing the Perimeter Wire
If the Perimeter Wire needs to be spliced, use a connector
supplied in the Robomow box. It is waterproof and gives a reliable
electrical connection.
IMPORTANT! Before slicing the Perimeter Wire, disconnect the
PowerBox from the power outlet.
1. Insert both wire ends in the connector at left-most and right-
most positions.
2. Conrmthatthewiresarefullyinsertedintotheconnector.
3. Use a pair of pliers to press down the button on top of the
connector. The button should be fully pressed, without
damaging the connector.
IMPORTANT! Neither twisted cables, nor a screw terminal
insulated with insulation tape are a satisfactory splice. Soil
moisture will cause such conductors to oxidize and will later lead
to a broken circuit.
11.7 Maintenance of the Base Station Area
• Keep the Base Station entrance and area clean of leaves,
sticks, twigs or any other debris that usually accumulates
in such areas.
• NEVER spray water directly towards the Base Station.
• Be careful when trimming around the Base Station with a
powered weed trimmer as damage to the Extension Cable
may occur.
• In the event of damage to any part of the Extension Cable,
stop the use of the mower and the Base Station. Disconnect
the Extension Cable and replace it.
11.8 Lightning storm
Warning! To reduce the risk of damage to components in the
case of a lightning storm, disconnect the Perimeter Wire from the
Base Station /Perimeter Switch and the Power Box 230V/120V
plug from the power outlet.

Robomow RC306 Specifications

General

Type	Robotic lawn mower
Cutting width	280 mm
Cutting system	-
Recommended lawn area	600 m²
Maximum cutting height	60 mm
Minimum cutting height	15 mm
Grass collecting volume	- L
Battery type	LiFePO4
Power source	Battery
Charging time	1 h
Battery voltage	26 V

Weight and Dimensions

Depth	460 mm
Width	630 mm
Height	210 mm
Weight	11400 g
