Robomow RM400 & Base Station User Manual

Chapter 2 - Menu
Chapter 2 introduces Robomow menu functions. To use the control panel read the instructions in
paragraph 1.2.4.
The main menu consists of four options: 2.1 Zones setup
2.2 Settings
2.3 Information
2.4 Service (password is required)
Note: the numbers 2.1-2.4 refer to the headings on the coming pages.
To browse through the main menu and the submenus, use the ‘
GO’ button as a means to select or
confirm different menu options or settings. Pressing the ‘
GO’ button will generally select or confirm the
text message shown on the second line of the LCD. There are several settings, which the user can make
changes to and features that can be enabled/disabled. Pressing the ‘
STOP’ button at any time during the
menu selection process will bring you one step back in the menu. To scroll between the submenus use
the ‘
UP’/’DOWN’ arrow keys.
To see the main menu functions (options 2.1 to 2.4 - Figure 2.1), follow one of the following options:
1. When the mower is out of the Base Station scroll down to the ‘User options’ display and press
‘GO’;
2. When the mower is in the Base Station, simply scroll down to the menu you want.
Figure number 2.1 shows the main menu and the submenus available under each of the options. There
are more submenus in the next level of the menu tree that are explained in the next pages of this chapter.
28
Figure 2.1
Robomow menu options
Operation
Battery
Temperatures
Configuration
Last stop cause
Child guard
Anti theft
Time and date
Rain sensor
Language
Blade replaced
Wire position
Delay operation
User options
Set Zone: Base
Set Zone: A
Set Zone: B
Service
Zones setup
Settings
Information
Password required
2.1
2.2
2.3
2.1.1
2.1.2
2.2.1
2.2.2
2.2.3
2.2.4
2.2.5
2.2.6
2.2.7
2.3.1
2.3.2
2.3.3
2.3.4
2.3.5
2.4
2.2.8
Operation
Battery
Temperatures
Configuration
Last stop cause
Child guard
Anti theft
Time and date
Rain sensor
Language
Blade replaced
Wire position
Delay operation
User options
Set Zone: Base
Set Zone: A
Set Zone: B
Service
Zones setup
Settings
Information
Service
Zones setup
Settings
Information
Password requiredPassword required
2.1
2.2
2.3
2.1.1
2.1.2
2.2.1
2.2.2
2.2.3
2.2.4
2.2.5
2.2.6
2.2.7
2.3.1
2.3.2
2.3.3
2.3.4
2.3.5
2.4
2.2.8
Scroll UP/DOWN
using the arrow keys
to the menu you want
and press GO to see
the options below the
chosen menu
Press GO to receive
options 2.1 to 2.3
