1.4 CONTROLS
1.4.1 Control device
The operation of the appliance is regulated by the control
panel supplied as standard, which includes a thermostat
for adjusting the temperature and a programmable timer
(standard on 3002 model, optional on 3001 model).
For further information please refer to Paragraph
6.2
p.20
.
1.5 TECHNICAL DATA
Table1.1 Technical data
3001 3002
Heating mode
Heat input nominal (1013 mbar - 15 °C) (1) kW 2,6
Heat output nominal kW 2,3
Eciency nominal heat input % 90,0
Electrical specications
Power supply
voltage V 230
type - single-phase
frequency Hz 50
Electrical power absorption nominal kW 0,05
Installation data
Gas consumption
G20 natural gas (nominal) m³/h 0,27
G25 (nominal) m³/h 0,31
G30 (nominal) kg/h 0,15
G31 (nominal) kg/h 0,20
Gas connection
type - M
thread “ 3/8
Flue gas exhaust
diameter (Ø) mm 50
type of installation - C13, C33, C63
residual head Pa 25
maximum equivalent length of coaxial exhaust duct m 1
sound power L
w
(max) dB(A) 47,5
sound pressure L
p
at 5 metres (max) dB(A) 28,5
Dimensions
width mm 478
height mm 577
depth mm 173
Weight in operation kg 17
(1) Relative to NCV (net caloric value).
2 TRANSPORT AND POSITIONING
2.1 WARNINGS
Damage from transport or installation
The manufacturer shall not be liable for any dam-
age during appliance transport and installation.
On-site inspection
Upon arrival at the site, ensure there is no transport
damage on packing.
After removing the packing materials, ensure the
appliance is intact and complete.
Packing
Only remove the packing after placing the appli-
ance on site.
Do not leave parts of the packing within the reach
of children (plastic, polystyrene, nails...) since they
are potentially dangerous.
Weight
The lifting equipment must be suitable for the load.
Lift up the unit and secure it to its support bracket
(Paragraph 3.5.1
p.14
).
2.2 HANDLING
2.2.1 Handling and lifting
▶
Always handle the appliance in its packing, as deliv-
ered by the factory.
▶
Comply with safety regulations at the installation site.
