Meter Memory, Setup, and Data Transfer
26
Transferring Results to a Computer
We oer a variety of software to help you transfer your results. For information on Accu‑Chek software,
contact Roche.
You can transfer your stored results to a computer to track, identify patterns, and print.
WARNING
Transferring data to a computer from meters used for multiple‑patient testing is NOT recommended
since individual patient results cannot be identified.
Transferring Data Directly to a Computer Using Specialized Software and an Infrared Cable
1. Install the software according to the instructions.
2. To transfer the results to a computer, connect the infrared cable according to the instructions.
3. Run the software program and follow the instructions for data transfer. Make sure the software is
ready to accept data from the meter.
4. With the meter o, press and hold both
and until 2arrows on the display alternately flash.
5. Locate the infrared (IR) window on the top of the meter.
6. Locate the IR window on the infrared cable.
7. Place the meter on a flat surface. Point the 2IR windows toward each other. They should be 3–10cm
apart.
8. Do not move the infrared cable or meter during the data transfer.
9. Follow the prompts on the software.
10. The software program may shut o the meter automatically when the data transfer is complete.
Should this occur, follow the prompts on the computer screen.
NOTE
• If the data did not transfer successfully, try again. Contact Roche if you still have problems.
• To make the most of the transfer feature, make sure the meter is set to the correct time and date.
