RocHobby F-16 Falcon - Install the Main Wing

page7
Assemble the plane
Install the main wing
4. Install the front landing gear. The flat
spot of the strut will be used to hold the
strut firmly into place (step 6 below).
5. Check the socket inside the air intake to
ensure the screw side of the socket faces
the nose of the plane.
6. Insert the front strut into the socket from
the bottom of the air intake with the flat spot
side toward the screws side of the socket.
1. Remove any paint (Tip - use strong
adhesive tape to easily remove paint)
where the main wing and the horizontal
stabilizer will fit together with the
fuselage.
2. Apply equal parts of quick dry epoxy into
the mixing plate and stir with a stick.
Note: Epoxy will dry in approx 3 to 5 min so
be sure you have adequate time to apply
glue and position parts.
5
6
1.1
1.2
2
4
For More Info Vist: www.motionrc.com
