Center of Gravity
When balancing your model, adjust the motor battery as necessary so the model is level or
slightly nose down. This the correct balance point for your model. After the first flights, the CG
position can be adjusted for your personal preference.
1. The recommended Center of Gravity (CG) location for your model is ( ) forward from170-172mm
the trailing edge of the main wing (as shown) with the battery pack installed. Mark the location of the
CG on top of the wing.
2. When balancing your model, support the plane inverted at the marks made on the top of the
main wing with your fingers or a commercially available balancing stand. This is the correct
balance point for your model. Make sure the model is assembled and ready for flight before
balancing.
page13
Assemble the plane
Check the C.G. (Center of Gravity)
170-172mm
