WhenaLi-Poisdischarged below 3V per cell, it will not hold a charge. The ESC protects
the flight battery from over-discharge using Low Voltage Cutoff. Before the battery charge
decreases too much, LVC removes power from motor in two ways: (1) Reduces power -
ESC reduces motor power (recommended), (2) Hard cutoff - ESC instantly cuts motor
power when the pre-set Low Voltage Protection Threshold value is reached. These
settings can be changed using the ESC programing guide (available on-line).
Low voltage cut off (LVC)
Assemble the plane
Install the landing gear
2
3
1. Slide L bend end of the landing gear
strut into the pre-notched slot on the
gear mounting base. Each strut should
installed so that the wheel faces
outwards when installed.
1.1
1.2
2. Rotate the strut as picture 1.2 shows
till the strut is fully seated into the slot.
3. Snap the plastic latch to secure the landing gear
into place.
