Using Steps:
1. Connect the charger to adapter with enough voltage and wattage, then the Power LED will
turn on;
2. Connect 2S/3S battery pack to the corresponding balance port (Do not connect two battery
packs at the same time), then the Charge LED will flicker (1Hz) and start charging.
3. When the Charge LED stops flickering, charging is complete, and the batteries can be
unplugged.
Charging Function Description
1. If all voltage of the installed battery pack is higher than 4.18V, charging will not start and the
charge LED will shine.
2. If the voltage of one battery or some batteries is lower than 0.7V, charging will not start. If the
voltage of the first battery of a 3S battery pack is lower than 0.7V, the charger will charge the
battery pack as if it was a 2S battery pack.
3. If the voltage of one battery or some batteries is lower than 2.8V, the charger will activate the
battery pack with a small current. If the voltage can’t be increased above 2.8V after half an
hour, the charger will judge the battery pack as bad. The charge LED will then flicker rapidly
(0.5Hz), and charging will stop.
Self Checking Function
1. Charger will perform a self test before each charge. The charge LED will rapidly flicker (0.5Hz)
if the charging function is abnormal;
2. Accuracy checking Function: Connect a fully charged 3S battery pack (all voltage at least 4.2V),
the charge LED will flicker twice then shine always. This means that the accuracy is normal.
Protection Function
1. Reverse connection protection of input
2. Reverse connection protection of output
3. Short circuit protection of output
4. Over voltage protection of output
Troubleshooting
1. Power LED does not shine – Adapter isn’t connected correctly. Please check the polarity
and reconnect adapter.
2. Charging abruptly stops and tries to restart constantly during charging – Output power
of the adapter is not sufficient, please replace the adapter.
3. Charge LED does not shine – Reconnect the battery pack; Check the voltage of batteries.
4. Charge LED rapidly flickers – Battery is bad or charging function is abnormal. Replace
battery or contact technical support.
page5
Charging the Flight Battery
