Assemble the plane
Install the vertical fin
1. Glue the vertical stabilizer into place.
2. The wrong way to mount the air speed
head.
4. The wrong way to mount the nose cone.
1. Glue the air speed head to the nose
cone. Ensure the air speed head and
nose cone are in perfect alignment.
Note: Use epoxy or other foam safe
adhesive when gluing to avoid damaging
the foam.
Install the nose cone
3
2
4
1
1
3. The nose cone is attached to the
fuselage using two pieces of magnets.
Figure 3 shows the right way to attach
the nose.
