Rockwell Automation Publication 1766-UM001O-EN-P - September 2021 141
Appendix A Specifications
Continuous current per
module, max
.
2.0 A at 55 °C (131 °F)
4.0 A at 30 °C (86 °F)
4.0 A at 55 °C;
8.0 A at 30 °C
4.0 A at 55
°
C (131 °F)
8.0 A at 30
°
C (86 °F)
4.0 A at 60 °C (140 °F) 4.0 A at 60 °C (140 °F)
Surge current, max.
5.0 A (Repeatability is once
every 2 s for a duration of
25 ms.
2.0 A (Repeatability is once
every 2 s at 55 °C (131 °F),
once every second at 30 °C
(86 °F) for a duration of
10 ms.)
2.0 A (Repeatability is once
every 2 s at 55 °C (131 °F),
once every second at 30 °C
(86 °F) for a duration of
10 ms.)
2.0 A (Repeatability is once
every 2 s at 60 °C (140 °F)
for 10 ms)
2.0 A (Repeatability is once
every 2 s at 60 °C (140 °F)
for 10 ms)
Isolated groups
Group 1: Outputs 0…3
Group 2: Outputs 4…7
Group 1: Outputs 0…7 Group 1: Outputs 0…15
Group 1: Outputs 0…15
Group 2: Outputs 16…31 (internally connected to common)
Output group to backplane
isolation
Verified by one of the
following dielectric tests:
1836V AC for 1 s or 2596V DC
for 1 s.
265V AC working voltage
(IEC Class 2 reinforced
insulation)
Verified by one of the following dielectric tests: 1200V AC
for 1 s or 1697V DC for 1 s.
75V DC working voltage (IEC Class 2 reinforced insulation)
Verified by one of the following dielectric tests: 1200V AC
for 2 s or 1697V DC for 2 s.
75V DC working voltage (IEC Class 2 reinforced insulation)
Output group to output
group isolation
Verified by one of the
following dielectric tests:
1836V AC for 1 s or 2596V DC
for 1 s.
265V AC working voltage
(IEC Class 2 reinforced
insulation)
Not applicable
Verified by one of the following dielectric tests: 1200V AC
for 2 s or 1697V DC for 2 s.
75V DC working voltage (IEC Class 2 reinforced insulation)
Vendor I.D. code 1
Product type code 7
Product code 119 101 1
03
100 102
Output Specifications – 1762-OA8, 1762-OB8, 1762-OB16, 1762-OB32T, 1762-OV32T (Continued)
Specification 1762-OA8 1762-OB8 1762-OB16 1762-OB32T 1762-OV32T
Output Specifications – 1762-OW8, 1762-OW16, 1762-OX6I, 1762-IQ8OW6
Specification 1762-OW8 1762-OW16 1762-OX6I 1762-IQ8OW6
Shipping weight, approx. (with carton) 228 g (0.50 lbs.) 285 g (0.63 lbs.) 220 g (0.485 lbs) 280 g (0.62 lbs.)
Voltage category AC/DC normally open relay AC/DC normally open relay AC/DC Type C Relay AC/DC normally open relay
Operating voltage range
5…265V AC
5…125V DC
5…265V AC
5…125V DC
5…265V AC
5…125V DC
5…265V AC
5…125V DC
Number of outputs 8 16 6 6
Bus current draw, max.
80 mA at 5V DC (0.40 W)
90 mA at 24V DC (2.16 W)
140 mA at 5V DC (0.70W)
(1)
180 mA at 24V DC (4.32 W)
(1)
110 mA at 5V DC (0.55W)
110 mA at 24V DC (2.64W)
110 mA at 5V DC
80 mA at 24V DC
Heat dissipation, max. 2.9 W
6.1 W
(1)
2.8 W
5.0 W at 30V DC
4.4 W at 26.4V DC (The Watts per
point, plus the min. W, with all
points energized.)
Signal delay, max. – resistive load
On Delay: 10 ms
Off Delay: 10 ms
On Delay: 10 ms
Off Delay: 10 ms
On Delay: 10 ms (max) 6 ms
(typical)
Off Delay: 20 ms (max)
12 ms (typical)
On-delay: 10 ms (max)
Off-delay: 10 ms (max)
Off-state leakage, max. 0 mA 0 mA 0 mA 0 mA
On-state current, min. 10 mA 10 mA 100 mA 10 mA
On-state voltage drop, max. Not Applicable
Continuous current per point, max.
2.
5 A. See Table 14 on page 142.
7A
See Table 15 on page 142.
2.5 A
See Table 14 on page 142.
Continuous current per common,
max.
8A 8A
7A
See Table 15 on page 142
.
8A
Continuous current per module, max. 16 A 16 A
30A
See Table 16 on page 142
.
8A
Surge current, max. See Table 14 on page 142
. See Table 15 on page 142. See Table 14 on page 142.
Isolated groups
Group 1: Outputs 0…3
Group 2: Outputs 4…7
Group 1: Outputs 0…7
Group 2: Outputs 8…15
All 6 Outputs Individually Isolated.
Group 3:
Outputs 0…5
Output group to backplane isolation
Verified by one of the following dielectric tests: 1836V AC for 1 s or 2596V DC for 1 s.
265V AC working voltage (IEC Class 2 reinforced insulation)
Output group to output group isolation
Verified by one of the following dielectric tests: 1836V AC for 1 s or 2596V DC for 1 s.
265V AC working voltage (basic insulation)
150V AC working voltage (IEC Class 2 reinforced insulation)
