Appendix A Specifications
Vendor I.D. code 1
Product type code 7
Product code 1
20 1 21 124 98
(1) Only applicable for Series B and Series C I/O modules.
Output Specifications – 1762-OW8, 1762-OW16, 1762-OX6I, 1762-IQ8OW6 (Continued)
Specification 1762-OW8 1762-OW16 1762-OX6I 1762-IQ8OW6
Table 14 - Relay Contact Ratings – 1762-OW8, 1762-OW16, and 1762-IQ8OW6
Maximum Volts Amperes Continuous
Amperes Volt-Amperes
Make Break Make Break
240V AC
2.5 A
(1)
(1) 1.5A above 40 °C (104 °F).
7.5 A 0.75 A 1800 VA 180 VA
120V AC
2.5 A
(1)
15 A 1.5 A 1800 VA 180 VA
125V DC 1.0 A
0.22 A
(2)
(2) For DC voltage applications, the make/break ampere rating for relay contacts can be determined by dividing 28 VA by the applied
DC voltage. For example, 28 VA/48V DC = 0.58 A. For DC voltage applications less than 14V, the make/break ratings for relay
contacts cannot exceed 2 A.
28 VA
24V DC 2.0 A
1.2 A
(2)
Table 15 - Relay Contact Ratings 1762-OX6I
Volts (max.)
Continuous
Amps per Point
(max.)
(1)
(1) The continuous current per module must be limited so the module power does not exceed 1440VA.
Amperes
(2)
(2) Surge Suppression – Connecting surge suppressors across your external inductive load will extend the life of the relay contacts.
For additional details, see Industrial Automation Wiring and Grounding Guidelines, publication 1770-4.1
.
Volt-Amperes
Make Break Make Break
240V AC 5.0 A 15 A 1.5 A
3600 VA 360 VA
120V AC
7.0 A
(3)
(3) 6 A in ambient temperatures above 40 °C (104.°F)
30 A 3.0 A
125V DC 2.5 A 0.4 A
50 VA
(4)
(4) DC Make/Break Volt-amperes must be limited to 50 VA for DC voltages between 28V DC and 125V DC. DC Make/Break Volt-amperes
below 28V DC are limited by the 7 A Make/Break current limit.
24V DC
7.0 A
(3)
7.0 A
168 VA
(4)
Table 16 - Module Load Ratings 1762-OX6I
Volts (max.) Controlled Load (Current) per Module (max.)
240V AC 6 A
120V AC
12 A
(1)
(1) Current per relay limited to 6 A at ambient temperatures above 40 °C (104.°F).
125V DC 11.5 A
24V DC
30 A
(2)
(2) 24 A in ambient temperatures above 40 °C (104.°F). Limited by ambient temperature and the
number of relays controlling loads. See Figure 65 on page 143.
