Rockwell Automation 1766-L32BWA User Manual

Rockwell Automation Publication 1766-UM001O-EN-P - September 2021 275
Appendix F MicroLogix 1400 Distributed Network Protocol
23 2
Frozen Counter Event – 16-bit with
flag
1 (read)
06 (no range, or all)
07, 08 (limited qty)
129 (response)
130 (unsol. resp)
17, 28 (index)
23 5
Frozen Counter Event – 32-bit with
flag and time
1 (read)
06 (no range, or all)
07, 08 (limited qty)
129 (response)
130 (unsol. resp)
17, 28 (index)
23 6
Frozen Counter Event – 16-bit with
flag and time
1 (read)
06 (no range, or all)
07, 08 (limited qty)
129 (response)
130 (unsol. resp)
17, 28 (index)
30 0 Analog Input – Any Variation 1 (read) 06 (no range, or all)
30 1 Analog Input – 32-bit with flag
1 (read) 06 (no range, or all) 129 (response) 00, 01 (start-stop)
30 2 Analog Input – 16-bit with flag 1 (read) 06 (no range, or all) 129 (response) 00, 01 (start-stop)
30 3 Analog Input – 32-bit without flag
1 (read) 06 (no range, or all) 129 (response) 00, 01 (start-stop)
30 4 Analog Input – 16-bit without flag
1 (read) 06 (no range, or all) 129 (response) 00, 01 (start-stop)
30 5
Analog Input – Single-prec flt-pt
with flag
1 (read) 06 (no range, or all) 129 (response) 00, 01 (start-stop)
32 0 Analog Input Event – Any Variation 1 (read)
06 (no range, or all)
07, 08 (limited qty)
32 1
Analog Input Event – 32-bit without
time
1 (read)
06 (no range, or all)
07, 08 (limited qty)
129 (response)
130 (unsol. resp)
17, 28 (index)
32 2
Analog Input Event – 16-bit without
time
1 (read)
06 (no range, or all)
07, 08 (limited qty)
129 (response)
130 (unsol. resp)
17, 28 (index)
32 3
Analog Input Event – 32-bit with
time
1 (read)
06 (no range, or all)
07, 08 (limited qty)
129 (response)
130 (unsol. resp)
17, 28 (index)
32 4
Analog Input Event – 16-bit with
time
1 (read)
06 (no range, or all)
07, 08 (limited qty)
129 (response)
130 (unsol. resp)
17, 28 (index)
32 5
Analog Input Event – Single-prec
flt-pt without time
1 (read)
06 (no range, or all)
07, 08 (limited qty)
129 (response)
130 (unsol. resp)
17, 28 (index)
32 7
Analog Input Event – Single-prec
flt-pt with time
1 (read)
06 (no range, or all)
07, 08 (limited qty)
129 (response)
130 (unsol. resp)
17, 28 (index)
40 0
Analog Output Status – Any
Variation
1 (read) 06 (no range, or all)
40 1
Analog Output Status – 32-bit with
flag
1 (read) 06 (no range, or all) 129 (response) 00, 01 (start-stop)
40 2
Analog Output Status – 16-bit with
flag
1 (read) 06 (no range, or all) 129 (response) 00, 01 (start-stop)
40 3
Analog Output Status – Single-prec
flt-pt with flag
1 (read) 06 (no range, or all) 129 (response) 00, 01 (start-stop)
41 1 Analog Output – 32-bit
3 (select)
4 (operate)
5 (direct op)
6 (dir. op, no ack)
17, 28 (index) 129 (response) echo of request
41 2 Analog Output – 16-bit
3 (select)
4 (operate)
5 (direct op)
6 (dir. op, no ack)
17, 28 (index) 129 (response) echo of request
41 3 Analog Output – Single-prec flt-pt
3 (select)
4 (operate)
5 (direct op)
6 (dir. op, no ack)
17, 28 (index) 129 (response) echo of request
50 1 Time and Date – Absolute time
1 (read) 07 (limited qty = 1) 129 (response)
07 (limited qty)
(qty = 1)
2 (write) 07 (limited qty = 1)
50 3
Time and Date – Absolute time at
last recorded time
51 1
Time and Date CTO – Absolute time,
synchronized
129 (response)
130 (unsol. resp)
07 (limited qty)
(qty = 1)
51 2
Time and Date CTO – Absolute time,
unsynchronized
129 (response)
130 (unsol. resp)
07 (limited qty)
(qty = 1)
52 1 Time Delay – Coarse 129 (response)
07 (limited qty)
(qty = 1)
Table 37 - Implementation Table for Series A controllers (Continued)
DNP Object Group & Variation
Request
DNP3 Master may issue
Controller must parse
Response
DNP3 Master must parse
Controller may issue
Group Num Var Num Description Function Codes (dec) Qualifier Codes (hex) Function Codes (dec) Qualifier Codes (hex)
