316 Rockwell Automation Publication 2080-UM002N-EN-E - November 2022
Appendix D Troubleshooting
Ethernet Diagnostics In Connected Components Workbench software, when the project in online, you can view the
status of the embedded Ethernet ports on the controller.
To see the Communication Diagnostic window, do the following.
1. Access the controller configuration.
2. Click Diagnose and select Communication.
