86 Rockwell Automation Publication 2080-UM002N-EN-E - November 2022
Chapter 6 Micro870 Controller Distributed Network Protocol
Update Key in Secure Authentication
This parameter is used to define user information Secure Authentication.
In Connected Components Workbench software, you can create the user keys in the DNP3
Slave configuration page.
User Number
Valid range is 1…65535.
User Role
A dropdown selection of various roles that you can define for each user number (Viewer,
Operator, Engineer, Installer, SECADM, SECAUD, RBACMNT, and single user).
User Name
Define the unique name for each user, up to 32 characters (numbers, alphabets, and symbols).
Update Key
The key to be used by each user, up to 32 hexadecimal digits.
To create a new user, follow these steps.
1. Click Configure to open Update Key.
2. Click Add.
3. Enter the User Number, select the User Role, enter the User Name, and enter the Update
Key.
4. Click Encrypt or OK to create the new user.
5. Download the project to the controller to update the user information in the controller.
To remove an existing user, follow these steps.
1. Click Configure to open Update Key.
2. Select the user to be removed and click Delete.
3. Click OK to close the window.
4. Download the project to the controller to update the user information in the controller.
