Rockwell Automation Publication 2080-UM002N-EN-E - November 2022 259

Chapter 12 Using microSD Cards

5. Click Upload. The progress bar should tell you whether the upload is successful or not.

A recipe header file is saved with the uploaded recipes.

IMPORTANT Do not remove the microSD card from the slot while data is being written

or retrieved from the card. Ongoing write and retrieval operations are

indicated by a flashing SD status LED.
