Rockwell Automation Publication 2080-UM002N-EN-E - November 2022 269
Appendix B Quickstarts
4. When you have confirmed the settings, click Update to begin flash updating the
controller.
The update progress is shown in the dialog box.
5. After the update is completed, the status is shown in the dialog box.
Flash Upgrade From MicroSD Card
With Connected Components Workbench software version 12 or later, and the microSD card
plug-in for Micro800 controllers, you can flash upgrade your Micro830, Micro850, and Micro870
controller from the microSD card in addition to using ControlFLASH. This is two-step process –
first you have to transfer the firmware to the microSD card using the SD Card Utility, then you
need to edit the ConfigMeFirst.txt file to initiate the flash upgrade process. See the following
instructions for performing the flash upgrade from the microSD card.
Step 1 – Transfer the Firmware to the microSD Card
1. Launch the Connected Components Workbench software.
2. Click Tools -> SD Card Utility.
IMPORTANT After control flashing the controller, some microSD cards may not be
detected. Remove and insert the microSD card, or power cycle the
controller if this issue is encountered.
