Appendix D Troubleshooting
Table 78 - General Diagnostic Parameters
Parameters Description
IP Statistics
IP Total Packets Sent Total number of IP packets successfully transmitted.
IP Total Packets Received Total number of IP packets successfully received.
IP Total Bytes Sent Total number of IP bytes successfully transmitted.
IP Total Bytes Received Total number of IP bytes successfully received.
IP Sent Packets Dropped Total number of IP packets dropped at sent.
IP Received Packets Dropped Total number of IP packets dropped at received.
IP Total Fragments Sent Total number of IP fragments sent.
IP Total Fragments Received Total number of IP fragments received.
IP Received Checksum Error Total number of IP packets received with checksum errors.
IP Invalid Packets Total number of invalid IP packets.
TCP Statistics
TCP Packets Sent Total number of TCP packets sent.
TCP Packets Received Total number of TCP packets received.
TCP Bytes Sent Total number of TCP bytes sent.
TCP Bytes Received Total number of TCP bytes received.
TCP Connections Dropped Total number of TCP connections dropped.
TCP Received Packets Dropped Total number of TCP packets dropped.
TCP Connections Total number of TCP connections.
TCP Disconnections Total number of TCP disconnections.
TCP Checksum Error Total number of TCP packets with checksum errors.
TCP Invalid Packets Total number of invalid TCP packets.
TCP Retransmit Packets Total number of TCP packets retransmitted.
UDP Statistics
UDP Packets Sent Total number of UDP packets sent.
UDP Packets Received Total number of UDP packets received.
UDP Bytes Sent Total number of UDP bytes sent.
UDP Bytes Received Total number of UDP bytes received.
UDP Received Packets Dropped Total number of UDP received packets dropped.
UDP Checksum Error Total number of UDP packets with checksum errors.
UDP Invalid Packets Total number of invalid UDP packets.
