Rockwell Automation 2080-LC70-24QWB User Manual

42 Rockwell Automation Publication 2080-UM002N-EN-E - November 2022
Chapter 3 Install Your Controller
Micro830 and Micro850 48-point Controllers (Front)
Micro830 and Micro850 48-point Controllers (Side)
45 (1.77)
33.8
(1.33)
7.2 (0.28)
7 (0.27)
108 (4.25)
108 (4.25)
230 (9.05)
7.8
(0.31)
(0.31)
27.8 (1.09)
7.8
44.4 (1.75)
14.4 (0.57)
216 (8.50)
7 (0.27)
22.8 (0.90)
36.6 (1.44)
90
100.1
110.8
(4.36)
(3.94)
(3.54)
Expansion I/O Slots
(Applicable to Micro850 only)
Single-width (1st slot)
Double-width (2nd slot)
2085-ECR (terminator)
Micro830/Micro850 48 pt Controller with Micro800 Power Supply
Measurements in mm (in.)
80 (3.15)
87
(3.42)
Expansion I/O Slots
(Applicable to Micro850 only)
Single-width (1st slot)
Double-width (2nd slot)
2085-ECR (terminator)
Micro830/Micro850 48-pt controller with Micro800 power supply
Measurements in mm (in.)
