88 Rockwell Automation Publication 2080-UM002N-EN-E - November 2022

Chapter 6 Micro870 Controller Distributed Network Protocol

Default Variation Config

This configuration is used to define default variations in a response to a Class 0 poll request.

In Connected Components Workbench software version 20.01.00 or later, you can select

Default Variation Table in the DNP3 Slave configuration page to change the configuration.

Example of a Public Key
