Rockwell Automation 2080-LC70-24QWB User Manual

Rockwell Automation Publication 2080-UM002N-EN-E - November 2022 91
Chapter 6 Micro870 Controller Distributed Network Protocol
33
Frozen 16-bit Analog Input Change Object 2 - 16-bit without time
0 - All variation
1 - 32-bit without time
3 - 32-bit with time
4 - 16-bit with time
5 - Single-precision, floating-point without time
6 - Double-precision, floating-point without time
7 - Single-precision, floating-point with time
8 - Double-precision, floating-point with time
Frozen 32-bit Analog Input Change Object 1 - 32-bit without time
0 - All variation
2 - 16-bit without time
3 - 32-bit with time
4 - 16-bit with time
5 - Single-precision, floating-point without time
6 - Double-precision, floating-point without time
7 - Single-precision, floating-point with time
8 - Double-precision, floating-point with time
Frozen Short Float Analog Input Change Object 5 - Single-precision, floating-point without time
0 - All variation
1 - 32-bit without time
2 - 16-bit without time
3 - 32-bit with time
4 - 16-bit with time
6 - Double-precision, floating-point without time
7 - Single-precision, floating-point with time
8 - Double-precision, floating-point with time
34
16-bit Analog Input Reporting Dead Band 1 - 16-bit
0 - All variation
2 - 32-bit
3 - Single-precision, floating-point
32-bit Analog Input Reporting Dead Band 2 - 32-bit
0 - All variation
1 - 16-bit
3 - Single-precision, floating-point
Short Float Analog Input Reporting Dead Band 3 - Single-precision, floating-point
0 - All variation
1 - 16-bit
2 - 32-bit
40
16-bit Analog Output Static Object 2 - 16-bit with flag
0 - All variation
1 - 32-bit with flag
3 - Single-precision, floating-point with flag
4 - Double-precision, floating-point with flag
32-bit Analog Output Static Object 1 - 32-bit with flag
0 - All variation
2 - 16-bit with flag
3 - Single-precision, floating-point with flag
4 - Double-precision, floating-point with flag
Short Float Analog Output Status 3 - Single-precision, floating-point with flag
0 - All variation
1 - 32-bit with flag
2 - 16-bit with flag
4 - Double-precision, floating-point with flag
42
16-bit Analog Output Change Object 2 - 16-bit without time
0 - All variation
1 - 32-bit without time
3 - 32-bit with time
4 - 16-bit with time
5 - Single-precision, floating-point without time
6 - Double-precision, floating-point without time
7 - Single-precision, floating-point with time
8 - Double-precision, floating-point with time
32-bit Analog Output Change Object 1 - 32-bit without time
0 - All variation
2 - 16-bit without time
3 - 32-bit with time
4 - 16-bit with time
5 - Single-precision, floating-point without time
6 - Double-precision, floating-point without time
7 - Single-precision, floating-point with time
8 - Double-precision, floating-point with time
Short Float Analog Output Change Object 5 - Single-precision, floating-point without time
0 - All variation
1 - 32-bit without time
2 - 16-bit without time
3 - 32-bit with time
4 - 16-bit with time
6 - Double-precision, floating-point without time
7 - Single-precision, floating-point with time
8 - Double-precision, floating-point with time
Table 7 - DNP3 Default Variation Configuration File (Continued)
Group Default Variation for the following Objects Standard Default Variation Alternate Default Variations
