10 Rockwell Automation Publication 2198-IN021A-EN-P - June 2020
Kinetix 5300 Single-axis EtherNet/IP Servo Drives Installation Instructions
Kinetix 5300 IEC (non-UL/CSA) Circuit Protection Specifications
2198-C1004-ERS
100…120V AC
Single phase
KTK-R-6 140U-D6D2-B40
2198-C1007-ERS KTK-R-10 140U-D6D2-B80
2198-C1015-ERS KTK-R-15 140U-D6D2-C12
2198-C1020-ERS KTK-R-25 140U-D6D2-C20
2198-C1004-ERS
200…240V AC
KTK-R-6 140U-D6D2-B40
2198-C1007-ERS KTK-R-10 140U-D6D2-B80
2198-C1015-ERS KTK-R-15 140U-D6D2-C12
2198-C1020-ERS KTK-R-25 140U-D6D2-C20
Drive Cat. No. AC Input Voltage, nom Phase
DIN gG Fuses
Amps, max
Miniature CB
Cat. No.
Molded Case CB
Cat. No.
2198-C1004-ERS
200…240V AC
Three phase
6 1489-M3C060 140U-D6D3-B40
2198-C1007-ERS 10 1489-M3C100 140U-D6D3-B80
2198-C1015-ERS 16 1489-M3C160 140U-D6D3-C12
2198-C1020-ERS 25 1489-M3C250 140U-D6D3-C20
2198-C2030-ERS 32 1489-M3C400 140U-D6D3-C30
2198-C2055-ERS 40 — 140G-G6C3-C50
2198-C2075-ERS 50 — 140G-G6C3-C60
2198-C4004-ERS
380…480V AC
2 1489-M3C030 140U-D6D3-B20
2198-C4007-ERS 6 1489-M3C060 140U-D6D3-B40
2198-C4015-ERS 12 1489-M3C100 140U-D6D3-B80
2198-C4020-ERS 16 1489-M3C130 140U-D6D3-C12
2198-C4030-ERS 25 1489-M3C200 140U-D6D3-C15
2198-C4055-ERS 32 1489-M3C350 140U-D6D3-C30
2198-C4075-ERS 32 1489-M3C400 140U-D6D3-C30
2198-C1004-ERS
100…120V AC
Single phase
6 1489-M2C060 140U-D6D2-B40
2198-C1007-ERS 10 1489-M2C100 140U-D6D2-B80
2198-C1015-ERS 16 1489-M2C160 140U-D6D2-C12
2198-C1020-ERS 25 1489-M2C250 140U-D6D2-C20
2198-C1004-ERS
200…240V AC
6 1489-M2C060 140U-D6D2-B40
2198-C1007-ERS 10 1489-M2C100 140U-D6D2-B80
2198-C1015-ERS 16 1489-M2C160 140U-D6D2-C12
2198-C1020-ERS 25 1489-M2C250 140U-D6D2-C20
Kinetix 5300 UL/CSA Circuit Protection Specifications (Continued)
Drive Cat. No. AC Input Voltage, nom Phase
Bussmann Fuses
Cat. No.
Molded Case CB
Cat. No.
