Rockwell Automation Allen-Bradley 1756-EN2F User Manual

Rockwell Automation Publication 1756-UM004D-EN-P - August 2022 61
Appendix A
ControlLogix Network Device Status Indicators
Status Indicators The following graphics show the status indicators for these modules
(extended-temperature versions not shown).
Figure 9 - 1756-EN2F, 1756-EN2T (Single-port Modules)
Figure 10 - 1756-EN2TR, 1756-EN3TR (Dual-port Modules)
Topic Page
Status Indicators 61
Diagnostic Web Pages 66
Access the Diagnostic Web Pages 66
LINK NET OK
OK Status Indicator
Module Status Display
Link Status
Indicator (LINK)
Network Status Indicator (NET)
Module Status Display
OK Status Indicator
Network Status Indicator (NET)
Link Status
Indicators (LINK)

Rockwell Automation Allen-Bradley 1756-EN2F Specifications

General

Brand	Rockwell Automation
Model	Allen-Bradley 1756-EN2F
Category	Network Hardware
Language	English
