Rockwell Automation Publication IOLINK-UM001A-EN-P - August 2017 17
Set up the 836P Sensor for IO-Link Mode Chapter 2
6. After connecting the sensor, you must create/open a project in Studio
5000 to establish communication with the controller and to add the
1734-AENTR adapter and 1734-4IOL IO-Link master module to
Controller Organizer Tree (see Configure the IO-Link Master on
page 23 and Register the 836P IODD on page 27 for detailed
instructions).
IMPORTANT Once the sensor adapter and the master module have been configured in the
Controller Organizer Tree and the 836P has been wired to the master
module, the green status indicator on the sensor flashes at a 1 Hz rate. This
flash indicates that it is operating in IO-Link mode.
