208 Rockwell Automation Publication 2080-UM002L-EN-E - November 2021
Appendix A Specifications
Data Log Performance
25 55% 54.50% 61.25% 57.3
25 65% 64.50% 71.25% 67.3
25 85% 84.50% 91.25% 87.3
25 95% 94.50% 100.00% 97.0
50 5% 4.00% 17.50% 9.7
50 10% 9.00% 22.50% 14.8
50 20% 19.00% 32.50% 24.7
50 40% 39.00% 52.50% 44.7
50 55% 54.00% 67.50% 59.6
50 65% 64.00% 77.50% 69.6
50 85% 84.00% 97.50% 89.5
50 95% 94.00% 100.00% 98.1
100 5% 3.00% 30.00% 14.7
100 10% 8.00% 35.00% 19.5
100 20% 18.00% 45.00% 19.6
100 40% 38.00% 65.00% 49.3
100 55% 53.00% 80.00% 64.0
100 65% 63.00% 90.00% 73.8
100 85% 83.00% 100.00% 92.4
100 95% 93.00% 100.00% 98.0
PTO Typical Readings (Continued)
Expected Duty Cycle
Typical Duty Cycle
(1.27 KΩ load)
Frequency (kHz) %Duty Cycle Minimum Maximum %Duty Cycle
Data Log – Data Payload vs. Performance Time
Parameter
Number of Characters
28 502 518 1028 1493 3676
Average write time per data log file
including all overheads
541.77 ms 1043.75 ms 1086.67 ms 1632.36 ms 1972.9 ms 2696.22 ms
Average write time excluding first
sample
500.40 ms 963.86 ms 999.14 ms 1472.36 ms 1818.33 ms 2545.92 ms
Average write time excluding all
overheads
479.10 ms 502.78 ms 493.03 ms 505.54 ms 519.91 ms 715.68 ms
