14 Rockwell Automation Publication 20P-TD001K-EN-P - January 2021
PowerFlex DC Drive and Field Controller Technical Data
AC Input Line Reactors and Contactors
If a DC contactor is used, an AC input contactor is not needed.
PowerFlex DC Drives – 230V AC Input
Frame
Drive Current Rating
Code
DC amps AC Line amps Hp
IP00 (Open Style) Line
Reactor Cat No.
Line Reactor kW (Hp)
AC Input Contactor
Cat. No.
A
7P0 7 5.7 1.5 1321-3R8-A 0.75 (1) 100-C12D10
9P0 9 7.4 2 1321-3R12-A 1.49 (2) 100-C12D10
012 12 9.8 3 1321-3R18-A
0.75…3.7 (1…5)
100-C12D10
020 20 16 5 1321-3R18-A 100-C23D10
029 29 24 7.5 1321-3R55-A
5.5…11 (7.5…15)
100-C30D10
038 38 31 10 1321-3R55-A 100-C37D10
055 55 45 15 1321-3R55-A 100-C60D10
073 73 60 20 1321-3R80-A 15 (20) 100-C60D10
093 93 76 25 1321-3R100-A
18.5…22 (25…30)
100-C85D10
110 110 90 30 1321-3R100-A
100-E11611
(1) (2)
(1) To order with built in terminal lugs, add the letter “L” to the end of the catalog number (example: 100-E11611L).
(2) The catalog number as listed is incomplete. See IEC Contactor Specifications Technical Data, publication 100-TD013, to select coil voltage and optional PLC interface terminals.
B
146 146 119 40 1321-3R160-A
30…37 (40…50)
100-E14611
(1) (2)
180 180 147 50 1321-3R160-A
100-E19011
(2)
218 218 178 60 1321-3RB250-A
45…56 (60…75)
100-E19011
(2)
265 265 217 75 1321-3RB250-A
100-E26511
(2)
360 360 294 100 1321-3RB320-A 75 (100)
100-E30511
(2)
434 434 355 125 1321-3RB400-A 93 (125)
100-E37011
(2)
C
521 521 426 150 1321-3R500-A 112 (150)
100-E46011
(2)
700 700 572 200 1321-3R600-A 149 (200)
100-E58011
(2)
D
875 875 715 250 1321-3R750-A 186 (250)
100-E75011
(2)
1K0 1050 858 300 1321-3R850-A 224 (300)
100-E86011
(2)
PowerFlex DC Drives – 460V AC Input
Frame
Drive Current
Rating Code
DC amps AC Line amps Hp
IP00 (Open Style)
Line Reactor Cat No.
Line Reactor kW (Hp)
AC Input
Contactor Cat. No.
A
4P1 4.1 3.3 2 1321-3R4-A 0.55 (0.75) 100-C12D10
6P0 6 4.9 3 1321-3R8-A 0.75 (1) 100-C12D10
010 10 8.2 5 1321-3R18-B
1.5…7.5 (2…10)
100-C12D10
014 14 11.4 7.5 1321-3R18-B 100-C12D10
019 19 15.5 10 1321-3R18-B 100-C23D10
027 27 22.1 15 1321-3R55-B
11…22 (15…30)
100-C23D10
035 35 28.6 20 1321-3R55-B 100-C30D10
045 45 36.8 25 1321-3R55-B 100-C37D10
052 52 42.5 30 1321-3R55-B 100-C43D10
073 73 59.6 40 1321-3R80-B 30 (40) 100-C60D10
086 86 70.3 50 1321-3R100-B
37…45 (50…60)
100-C85D10
100 100 81.7 60 1321-3R100-B 100-C85D10
129 129 105.4 75 1321-3R160-B
56…75 (75…100)
100-E11611
(1) (2)
B
167 167 136.4 100 1321-3R160-B
100-E14611
(1) (2)
207 207 169.1 125 1321-3RB250-B
93…112 (125…)
100-E19011
(2)
250 250 204.3 150 1321-3RB250-B
100-E20511
(2)
330 330 269.6 200 1321-3RB320-B 149 (200)
100-E30511
(2)
412 412 336.6 250 1321-3RB400-B 186.4 (250)
100-E37011
(2)
