Rockwell Automation Allen-Bradley PowerFlex 20P User Manual

Rockwell Automation Publication 20P-TD001K-EN-P - January 2021 15
PowerFlex DC Drive and Field Controller Technical Data
C
49
5 495 404.4 300 1321-3R500-B 223.7 (300)
100-E46011
(2)
667 667 544.9 400 1321-3R600-B 298.3 (400)
100-E58011
(2)
D
830 830 678.1 500 1321-3R750-B 372.8 (500)
100-E75011
(2)
996 996 813.7 600 1321-3R850-B 447.4 (600)
100-E86011
(2)
1K1 1162 949.4 700 1321-3R1000-B 552 (700)
100-E106011
(2)
1K3 1328 1085.0 800 2 x1321-3R600-B 596.6 (800)
(1)
1K4 1494 1220.6 900 2 x1321-3R600-B 671.1 (900)
(1)
(1) To order with built in terminal lugs, add the letter “L” to the end of the catalog number (example: 100-E11611L).
(2) The catalog number as listed is incomplete. See IEC Contactor Specifications Technical Data, publication 100-TD013, to select coil voltage and optional PLC interface terminals.
PowerFlex DC Drives – 575V AC Input
Frame
Drive Current Rating
Code
DC amps AC Line amps Hp
IP00 (Open Style)
Line Reactor Cat No.
Line Reactor kW (Hp)
AC Input Contactor Cat.
No.
B
067 67.5 55.1 50 1321-3R55-B 37 (50) 100-C60D10
101 101.25 82.7 75 1321-3R100-B 56 (75) 100-C85D10
135 135 110.3 100 1321-3R130-B 75 (100)
100-E116x11
(1) (2)
(1) To order with built in terminal lugs, add the letter “L” to the end of the catalog number (example: 100-E11611L).
(2) The catalog number as listed is incomplete. See IEC Contactor Specifications Technical Data, publication 100-TD013, to select coil voltage and optional PLC interface terminals.
270 270 220.6 200 1321-3RB250-B 149 (200)
100-E30511
(2)
405 405 330.9 300 1321-3RB320-B 224 (300)
100-E37011
(2)
C
540 540 441.2 400 1321-3R500-B 298 (400)
100-E46011
(2)
675 675 551.5 500 1321-3R600-B 373 (500)
100-E58011
(2)
D
810 810 661.8 600 1321-3R750-B 447 (600)
100-E75011
(2)
1K0 1080 882.4 800 1321-3R1000-B 597 (800)
100-E106011
(2)
1K2 1215 992.7 900 1321-3R1000-B 671 (900)
100-E106011
(2)
1K3 1350 1103.0 1000 2 x 1321-3R600-B 746 (1000)
(3)
(3) No AC Input contactor available for this drive rating - must be sourced locally.
1K6 1687.5 1378.7 1250 2 x 1321-3R750-B —
(3)
PowerFlex DC Drives – 690V AC Input Drives
Frame
Drive Current Rating
Code
DC amps AC Line amps Hp
IP00 (Open Style)
Line Reactor Cat No.
Line Reactor kW (Hp)
AC Input Contactor Cat.
No.
C
452 452 369 400 1321-3R500-C
—
100-E46011
(1)
(1) The catalog number as listed is incomplete. See IEC Contactor Specifications Technical Data, publication 100-TD013, to select coil voltage and optional PLC interface terminals.
565 565 462 500 1321-3R600-C
100-E58011
(1)
D
678 678 554 600 1321-3R750-C
100-E58011
(1)
791 791 646 700 1321-3R750-C
100-E75011
(1)
904 904 739 800 1321-3R1000-C
100-E75011
(1)
1K0 1017 831 900 1321-3R1000-C
100-E86011
(1)
1K1 1130 923 1000 2 x 1321-3R600-C
100-E106011
(1)
1K2 1243 1016 1100 2 x 1321-3R600-C
100-E106011
(1)
1K4 1412.5 1154 1250 2 x 1321-3R750-C
(2)
(2) No AC Input contactor available for this drive rating - must be sourced locally.
1K5 1582 1292 1400 2 x1321-3R750-C
(2)
PowerFlex DC Drives – 460V AC Input (Continued)
Frame
Drive Current
Rating Code
DC amps AC Line amps Hp
IP00 (Open Style)
Line Reactor Cat No.
Line Reactor kW (Hp)
AC Input
Contactor Cat. No.

Rockwell Automation Allen-Bradley PowerFlex 20P Specifications

General

Brand	Rockwell Automation
Model	Allen-Bradley PowerFlex 20P
Category	DC Drives
Language	English
