16 Rockwell Automation Publication 20P-TD001K-EN-P - January 2021
PowerFlex DC Drive and Field Controller Technical Data
PowerFlex DC Field Controller AC Input Line Reactors and AC Contactors
These tables contain the recommended AC input line reactors and AC contactors for use with the PowerFlex DC field controller.
IMPORTANT An AC input contactor can only be used when the device is used in ‘standalone’ mode. An AC contactor for a device
cannot be used when a PowerFlex DC field controller is paired with and controlled by a PowerFlex DC drive.
ATTENTION: Do not remove AC power until the field controller output (load) current is zero. Equipment damage can occur.
PowerFlex DC Field Controller – 200V AC Input
Frame
Field Controller Cat.
No.
DC amps AC Line amps
IP00 (Open Style) Line Reactor
Cat No.
Line Reactor kW AC Input Contactor Cat. No.
A
23PFCB017 17 14.45 1321-3R18-A 0.75…3.7 100-C23D10
23PFCB060 60 51 1321-3R80-A 15 100-C60D10
23PFCB120 120 102 1321-3R160-A 30…37
100-E11611
(1) (2)
(1) To order with built in terminal lugs, add the letter “L” to the end of the catalog number (example: 100-E11611L).
(2) The catalog number as listed is incomplete. See IEC Contactor Specifications Technical Data, publication 100-TD013, to select coil voltage and optional PLC interface terminals.
B
23PFCB245 245 208 1321-3RB250-A 45…56
100-E26511
(2)
23PFCB365 365 310 1321-3RB400-A 93
100-E37011
(2)
23PFCB570 570 485 1321-3R600-A 149
100-E58011
(2)
PowerFlex DC Field Controller – 500V AC Input
Frame
Field Controller Cat.
No.
DC amps AC Line amps
IP00 (Open Style)
Line Reactor Cat No.
Line Reactor kW AC Input Contactor Cat. No.
A
23PFCD017 17 14.45 1321-3R18-B 1.5…7.5 100-C23D10
23PFCD060 60 51 1321-3R80-B 30 100-C60D10
23PFCD120 120 102 1321-3R160-B 56…75
100-E11611
(1) (2)
(1) To order with built in terminal lugs, add the letter “L” to the end of the catalog number (example: 100-E11611L).
(2) The catalog number as listed is incomplete. See IEC Contactor Specifications Technical Data, publication 100-TD013
, to select coil voltage and optional PLC interface terminals.
B
23PFCD245 245 208 1321-3RB250-B 93…112
100-E26511
(2)
23PFCD365 365 310 1321-3RB400-B 186.4
100-E37011
(2)
23PFCD570 570 485 1321-3R600-B 298.3
100-E58011
(2)
