18 Rockwell Automation Publication 20P-TD001K-EN-P - January 2021
PowerFlex DC Drive and Field Controller Technical Data
460V AC Input Drives
Frame
Drive Current
Rating Code
DC
Amps
AC Line
Amps
Hp
Dynamic Brake
Resistor Kit Cat. No.
Armature
Voltage
(Volts)
Total dB
Resistance
(ohms)
DC Loop Contactor Cat. No.
(1)
(1) Coil voltage = 115V AC, 50/60Hz.
DC Contactor
Crimp Lugs
Cat. No.
(2)
(2) For more information, see DC Contactor Crimp Lug Kit Specifications on page 19.
Drive without
Dynamic Brake
Drive with
Dynamic Brake
A
4P1 4.1 3.3 2 1370-DBH63
500
81
1370-NC56
1370-DC56 1370-LG40
6P0 6 4.9 3 1370-DBH64 62
010 10 8.2 5 1370-DBH65 45
014 14 11.4 7.5 1370-DBH66 27
019 19 15.5 10 1370-DBH67 20
027 27 22.1 15 1370-DBH68 12
035 35 28.6 20 1370-DBH69 10
1370-DC56
1370-LG40
045 45 36.8 25 1370-DBH70 9
1370-LG52
052 52 42.5 30 1370-DBH71 7
073 73 59.6 40 1370-DBH72 5.2
1370-NC110 1370-DC110
1370-LG92
086 86 70.3 50 1370-DBH73 4
100 100 81.7 60 1370-DBH74 4 1370-LG110
129 129 105.4 75 1370-DBH75 3
1370-NC180 1370-DC180
1370-LG140
B
167 167 136.4 100 1370-DBH76
2.1
1370-LG180
207 207 169.1 125 1370-DBH77
1370-NC280
1370-DC280 1370-LG228
250 250 204.3 150 1370-DBH78 1.5 1370-DC280 1370-LG268
330 330 269.6 200 1370-DBH79 1.05 ABB_EHDB360C2P-1L2S ABB_EHDB360C-1L22SS
(3)
(3) Wire and lug size dependent on enclosure dimensions and local codes.
412 412 336.6 250 HUBBELL_Y95W808GB 1
ABB_EHDB520C2P-1L2S ABB_EHDB520C-1L22SS
C
495 495 404.4 300 HUBBELL_Y101W595GB 0.8
667 667 544.9 400 HUBBELL_Y109W542GB 0.625 ABB_EHDB800C2P-1L2S ABB_EHDB800C-1L22SS
D
800 830 678.1 500
(4)
(4) No dynamic brake resistor kit available for this drive rating—must be sourced locally.
0.463 ABB_EHDB960C2P-1L2S ABB_EHDB960C-1L22SS
960 996 813.7 600
0.322
SIEMENS-MFG_14-193-
101-58-2 (Qty 2)
SIEMENS-MFG_14-193-101-
58-2 (Qty 1)
1K1 1162 949.4 700
1K3 1328 1085.0 800
0.255
CUTLER-
HAMMER_6702ED636-2
(Qty 2)
CUTLER-
HAMMER_6702ED636-2
(Qty 1)
1K4 1494 1220.6 900
