Rockwell Automation Publication 20P-TD001K-EN-P - January 2021 55
PowerFlex DC Drive and Field Controller Technical Data
Fuses for Regenerative Frame C and D Drives
Leg fuses are internally mounted and provided with frames C and D drives. See Fuse Code FS4 in PowerFlex DC Drive Frame C and D Fuse
Information on page 53
. Also, see Frame C Regenerative Drive - Leg Fuse Location and Frame D Regenerative Drive - Leg Fuse Location on
page 56
.
Leg Fuses - 230V AC Input Frame C Drives
Frame
Drive Current
Rating Code
DC
Amps
AC Line
Amps
Qty
Bussmann Mersen SIBA
Square Body - Flush End Contact
C
521 521 426
6 170M5464 + switch 170H0069 6,9 URD 32 TTF 800 + switch MS 3-V1-5 BS 20 671 32.800 + switch 28 001 04
700 700 571
Leg Fuses - 230V AC Input Frame D Drives
Frame
Drive Current
Rating Code
DC
Amps
AC Line
Amps
Qty
Bussmann Mersen SIBA
Square Body - DIN 43653 Stud-Mount
D
875 875 715
6
170M6263 + switch 170H0069 Y300263 + switch MS 3V 1-5 UR 20 635 32.900 + switch 28 001 04
1K0 1050 858 170M6264 + switch 170H0069 Z300264 + switch MS 3V 1-5 UR 20 635 32.1000 + switch 28 001 04
Leg Fuses - 460V AC Input Frame C Drives
Frame
Drive Current
Rating Code
DC
Amps
AC Line
Amps
Qty
Bussmann Mersen SIBA
Square Body - Flush End Contact
C
495 495 404.4
6
170M5462 + switch 170H0069 6,9 URD 32 TTF 630 + switch MS 3-V1-5 BS 20 671 32.630 + switch 28 001 04
667 667 544.9 170M5464 + switch 170H0069 6,9 URD 32 TTF 800 + switch MS 3-V1-5 BS 20 671 32.800 + switch 28 001 04
Leg Fuses - 460V AC Input Frame D Drives
Frame
Drive Current
Rating Code
DC
Amps
AC Line
Amps
Qty
Bussmann Mersen SIBA
Square Body - DIN 43653 Stud-Mount
D
830 830 678.1
6
170M6262 + switch 170H0069 X300262 + switch MS 3V 1-5 UR 20 635 32.800 + switch 28 001 04
996 996 813.7 170M6264 + switch 170H0069 Z300264 + switch MS 3V 1-5 UR 20 635 32.1000 + switch 28 001 04
1K1 1162 949.4 170M6265 + switch 170H0069 A300262 + switch MS 3V 1-5 UR 20 635 32.1100 + switch 28 001 04
1K3 1328 1085.0 170M6266 + switch 170H0069 B300266 + switch MS 3V 1-5 UR 20 635 32.1250 + switch 28 001 04
1K4 1494 1220.6 170M6267 + switch 170H0069 C300267 + switch MS 3V 1-5 UR 20 635 32.1400 + switch 28 001 04
Leg Fuses - 575V AC Input Frame C Drives
Frame
Drive Current
Rating Code
DC
Amps
AC Line
Amps
Qty
Bussmann Mersen SIBA
Square Body - Flush End Contact
C
540 540 441
6 11 URD 72 TTF 0800 + switch MS 3V 1-5 BS 20 771 32.800 + switch 28 001 04
675 675 551
Leg Fuses - 575V AC Input Frame D Drives
Frame
Drive Current
Rating Code
DC
Amps
AC Line
Amps
Qty
Bussmann Mersen SIBA
Square Body - DIN 43653 Stud-Mount
D
810 810 661
6
170M6246 + switch 170H0069 J300572 + switch MS 3V 1-5 UR 20 735 32.800 + switch 28 001 04
1K0 1080 881 170M6248 + switch 170H0069 L300574 + switch MS 3V 1-5 UR 20 735 32.1000 + switch 28 001 04
1K2 1215 991
12
170M6244 + switch 170H0069 G300570 + switch MS 3V 1-5 UR 20 735 32.630 + switch 28 001 04
1K3 1350 1102 170M6245 + switch 170H0069 H300571 + switch MS 3V 1-5 UR 20 735 32.700 + switch 28 001 04
1K6 1688 1377 170M6246 + switch 170H0069 J300572 + switch MS 3V 1-5 UR 20 735 32.800 + switch 28 001 04
