Rockwell Automation Publication 20P-TD001K-EN-P - January 2021 57
PowerFlex DC Drive and Field Controller Technical Data
Fuses for Non-Regenerative Frame C and D Drives
AC input line and/or leg fuses are internally mounted and provided with frames C and D drives. See Fuse Code FS4 in PowerFlex DC Drive
Frame C and D Fuse Information on page 53
. Also, see Frame C Non-Regenerative Drive - AC Input Line Fuse Location on page 58.
AC Input Line Fuses - 230V AC Input Frame C
Frame
Drive Current
Rating Code
DC
Amps
AC
Line
Amps
Qty
Bussmann Mersen SIBA
Square Body - Flush End Contact
C
521 521 426
3 170M5466 + switch 170H0069 6,9 URD 32 TTF 1000 + switch MS 3-V1-5 BS 20 671 32.1000 + switch 28 001 04
700 700 571
Leg Fuses - 230V AC Input Frame D Drives
Frame
Drive Current
Rating Code
DC
Amps
AC
Line
Amps
Qty
Bussmann Mersen SIBA
Square Body - DIN 43653 Stud-Mount
D
875 875 715
6
170M6263 + switch 170H0069 Y300263 + switch MS 3V 1-5 UR 20 635 32.900 + switch 28 001 04
1K0 1050 858 170M6264 + switch 170H0069 Z300264 + switch MS 3V 1-5 UR 20 635 32.1000 + switch 28 001 04
AC Input Line Fuses - 460V AC Input Frame C
Frame
Drive Current
Rating Code
DC
Amps
AC
Line
Amps
Qty
Bussmann Mersen SIBA
Square Body - Flush End Contact
C
495 495 404.4
3
170M5464 + switch 170H0069 6,9 URD 32 TTF 800 + switch MS 3-V1-5 BS 20 671 32.800 + switch 28 001 04
667 667 544.9 170M5466 + switch 170H0069 6,9 URD 32 TTF 1000 + switch MS 3-V1-5 BS 20 671 32.1000 + switch 28 001 04
Leg Fuses - 460V AC Input Frame D Drives
Frame
Drive Current
Rating Code
DC
Amps
AC Line
Amps
Qty
Bussmann Mersen SIBA
Square Body - DIN 43653 Stud-Mount
D
830 830 678.1
6
170M6262 + switch 170H0069 X300262 + switch MS 3V 1-5 UR 20 635 32.800 + switch 28 001 04
996 996 813.7 170M6264 + switch 170H0069 Z300264 + switch MS 3V 1-5 UR 20 635 32.1000 + switch 28 001 04
1K1 1162 949.4 170M6265 + switch 170H0069 A300262 + switch MS 3V 1-5 UR 20 635 32.1100 + switch 28 001 04
1K3 1328 1085.0 170M6266 + switch 170H0069 B300266 + switch MS 3V 1-5 UR 20 635 32.1250 + switch 28 001 04
1K4 1494 1220.6 170M6267 + switch 170H0069 C300267 + switch MS 3V 1-5 UR 20 635 32.1400 + switch 28 001 04
AC Input Line Fuses - 575V AC Input Frame C Drives
Frame
Drive Current
Rating Code
DC
Amps
AC Line
Amps
Qty
Bussmann Mersen SIBA
Square Body - Flush End Contact
C
540 540 441
3 170M5466 + switch 170H0069 6,9 URD 32 TTF 1000 + switch MS 3V 1-5 BS 20 671 32.1000 + switch 28 001 04
675 675 551
Leg Fuses - 575V AC Input Frame D Drives
Frame
Drive Current
Rating Code
DC
Amps
AC Line
Amps
Qty
Bussmann Mersen SIBA
Square Body - DIN 43653 Stud-Mount
D
810 810 661
6
170M6262 + switch 170H0069 X300262 + switch MS 3V 1-5 UR 20 635 32.800 + switch 28 001 04
1K0 1080 881 170M6264 + switch 170H0069 Z300264 + switch MS 3V 1-5 UR 20 635 32.1000 + switch 28 001 04
1K2 1215 991 170M6265 + switch 170H0069 A300262 + switch MS 3V 1-5 UR 20 635 32.1100 + switch 28 001 04
1K3 1350 1102 170M6266 + switch 170H0069 B300266 + switch MS 3V 1-5 UR 20 635 32.1250 + switch 28 001 04
1K6 1688 1377 12 170M6262 + switch 170H0069 X300262 + switch MS 3V 1-5 UR 20 635 32.800 + switch 28 001 04
