10 PowerFlex 700S Phase II Drives DriveLogix Option Card Battery Extension Cable
7. Mount the battery holder on the metal ground plate (as shown below)
using the hardware included.
8. Connect the existing battery to the extension cable connector and insert
the battery into the holder.
Connect battery to
extension cable
