Rockwell Automation Publication 750-UM002H-EN-P - February 2017 15
Chapter 2
Installation and Wiring
This chapter provides installation, jumper settings, and wiring for the
PowerFlex® 750-Series Safe Torque Off option module.
Installation must be in accordance with the following steps and must be carried
out by competent personnel. The Safe Torque Off option module is intended
to be part of the safety related control system. Before installation, perform a
risk assessment that compares the Safe Torque Off option module
specifications and all foreseeable operational and environmental characteristics
of the control system.
A safety analysis of the machine section controlled by the drive is required to
determine how often to test the safety function for proper operation during the
life of the machine.
Topic Page
Access the Drive Control Pod 16
Set the Safety Enable Jumper 20
Remove Power From the Drive System 21
Wire the Safety Option Module 25
Verify Operation 27
ATTENTION: The following information is merely a guide for proper
installation. Rockwell Automation, Inc. cannot assume responsibility for the
compliance or the noncompliance to any code, national, local or otherwise
for the proper installation of this equipment. A hazard of personal injury
and/or equipment damage exists if codes are ignored during installation.
IMPORTANT During installation and maintenance, check your drive firmware release
notes for known anomalies and verify that there are no safety-related
anomalies.
