Troubleshooting 4-7
PowerFlex 40 Adjustable Frequency AC Drive FRN 1.xx - 7.xx User Manual
Publication 22B-UM001I-EN-E
Drive does not respond to changes in speed command.
Motor and/or drive will not accelerate to commanded speed.
Cause(s) Indication Corrective Action
No value is coming from the
source of the command.
The drive “Run” indicator is lit
and output is 0 Hz.
• Check d012
[Control Source] for
correct source.
• If the source is an analog input,
check wiring and use a meter to
check for presence of signal.
• Check d002
[Commanded Freq]
to verify correct command.
Incorrect reference source is
being selected via remote
device or digital inputs.
None • Check d012
[Control Source] for
correct source.
• Check d014
[Dig In Status] to
see if inputs are selecting an
alternate source. Verify settings
for A051
- A054 [Digital Inx Sel].
• Check P038
[Speed Reference]
for the source of the speed
reference. Reprogram as
necessary.
• Review the Speed Reference
Control chart on page 1-23
.
Cause(s) Indication Corrective Action
Acceleration time is excessive. None Reprogram P039
[Accel Time 1] or
A067
[Accel Time 2].
Excess load or short
acceleration times force the
drive into current limit, slowing
or stopping acceleration.
None Compare d003
[Output Current] with
A089
[Current Limit 1].
Remove excess load or reprogram
P039
[Accel Time 1] or A067 [Accel
Time 2].
Check for improper A084
[Boost
Select] setting.
Speed command source or
value is not as expected.
None Verify d002
[Commanded Freq].
Check d012
[Control Source] for the
proper Speed Command.
Programming is preventing the
drive output from exceeding
limiting values.
None Check P035
[Maximum Freq] to
insure that speed is not limited by
programming.
Torque performance does not
match motor characteristics.
None Set motor nameplate full load amps
in parameter A126
[Motor NP FLA].
Perform A127
[Autotune] “Static
Tune” or “Rotate Tune” procedure.
Set A125
[Torque Perf Mode] to
option 0 “V/Hz”.
22B-UM001.book Page 7 Tuesday, May 30, 2017 5:22 PM
