ArmorStart
®
EtherNet/IP
™
Communications & Control Programming Manual Appendix A
This section explains the various bits in the Trip Status word and the faults they
represent.
Bulletin 280E Trip Status
The table below shows the default input (produced) assembly for Bulletin 280E.
Bytes 10 and 11 make up the word called Parameter 14, Prod Assy Word 1. The
Prod Assy Word points to a parameter and returns the value of that parameter. In
this case, Parameter 14 Prod Assy Word 1 points to parameter 4, which is the
Tr ip S t a t us parameter. Cross reference the parameter 14, Prod Assy Word 1 value
to the Trip Status parameter definition to understand what faults are being
reported.
Instance 150 "Starter Stat" – Default Status Assembly for Bulletin 280E/281E Starters
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Reserved (Referenced in the Add-On-Profile as “Fault”)
1 Reserved (Referenced in the Add-On-Profile as “Fault”)
2 Reserved (Referenced in the Add-On-Profile as “Fault”)
3 Reserved (Referenced in the Add-On-Profile as “Fault”)
4 — — — Ready Running Rev Running Fwd Warning Tripped
5 — — 140M On HOA Input 4 Input 3 Input 2 Input 1
6 Net Out 7 Net Out 6 Net Out 5 Net Out 4 Net Out 3 Net Out 2 Net Out 1 Net Out 0
7 Logic Enable Net Out 14 Net Out 13 Net Out 12 Net Out 11 Net Out 10 Net Out 9 Net Out 8
8 Value of the parameter pointed to by "Parameter 13 Prod Assy Word 0" (low byte)
9 Value of the parameter pointed to by "Parameter 13 Prod Assy Word 0" (high byte)
10 Value of the parameter pointed to by "Parameter 14 Prod Assy Word 1" (low byte)
11 Value of the parameter pointed to by "Parameter 14 Prod Assy Word 1" (high byte)
12 Value of the parameter pointed to by "Parameter 15 Prod Assy Word 2" (low byte)
13 Value of the parameter pointed to by "Parameter 15 Prod Assy Word 2" (high byte)
14 Value of the parameter pointed to by "Parameter 16 Prod Assy Word 3" (low byte)
15 Value of the parameter pointed to by "Parameter 16 Prod Assy Word 3" (high byte)
Trip Status
This parameter provides trip
identification.
Parameter Number 4
Access Rule GET
Data Type WORD
Group Basic Status
Units —
Minimum Value 0
Maximum Value 16383
Default Value 0
Point to
parameter 4,
Trip Status
